Charging Port Voltage Tester POWER Z USB Phone Current Meter KM001

Charging Port Voltage Tester POWER Z USB Phone Current Meter KM001

9 in stock

Regular price £70.83
Regular price Sale price £70.83
Sale Sold out
Shipping calculated at checkout.

SKU:

SKU:powerZ

Description:

ChargerLAB POWER-Z USB PD Tester Voltage Current Ripple Dual Type-C Meter KM001

POWER-Z USB PD Tester by ChargerLAB is a profenssional multitool allowing users to measure charging speed and diagnosing faults on mobile devices. Used by our team to quickly pinpoint defects related to charging/power usage. Fitted with a MicroUSB port, Type-C interface integrated together but also can be used to measure QC3.0 / 2.0 and other fast charge methods.



This tool is remarkably useful for determining common faults on Apple devices such as a damaged Power Management IC or U2 Charging IC allowing the user to avoid the intermittency that mobile repairs can be accompanied with therefore granting quicker repair times.



POWER-Z KM001 comes with an OLED screen resolution of 128 × 64. The front panel with black glass fiber gold-plated, four corners of the use of immersion gold hole fixed, the appearance and size of the USB table is no different from ordinary, ordinary users will soon be able to get started. USB table built-in a measurement accuracy of 0.02%, temperature drift for the 10ppm voltage and current ADC dedicated chip. At the same time in order to ensure the accuracy of the current, but also integrates a typical temperature drift of 20ppm, power of 3W high-quality sampling resistor. Up to 0.01% error.


POWER-Z KM001 This test table integrates a total of six USB ports, to meet the needs of most of the players test. Another feature of it is to support ripple testing. Its function is similar to a micro-oscilloscope, you can test less than 50Hz ripple, the daily use of enough.
